PVDF Fluorocarbon Powder Coatings
Fluorocarbon powder coatings offer the highest level of weathering performance and color durability for premium architectural applications.
Key Features
- Exceptional UV resistance and long-term color retention
- Superior anti-corrosion performance in coastal environments
- Ideal for curtain walls and high-end aluminum finishing
- Meets demanding architectural performance requirements
Typical Specifications
- Film thickness: 60–120 µm (typical)
- Gloss: matte, satin, semi-gloss, high-gloss
- Colors: RAL, Pantone or custom-matched
- Cure schedule confirmed with our engineers
Applications
Curtain walls, aluminum window and door profiles, building facades and premium outdoor products.
Typical parameters for reference — the final technical data sheet is confirmed by our engineers for your specific substrate and curing line.
Buyer Decision Snapshot
Choose PVDF when the project is high-value architectural aluminum, curtain walls, facades and projects needing excellent color/gloss retention in strong sun.. For standard indoor goods, a polyester or hybrid system may be more economical. Confirm the final selection with your substrate, cure oven and warranty requirements.
Specification to send with your inquiry
- Substrate and pretreatment line
- Interior or exterior service environment
- RAL / Pantone / custom color and gloss
- Target film thickness and cure window
- Required tests, certificates and market
- Quantity per color and destination port
- Repeat volume or annual program forecast
Commercial terms we confirm before quoting
We confirm MOQ, sample quantity, development and production time, QC documents, freight options and payment terms in one quotation, so buyers can compare the total delivered cost instead of only the ex-works price.
Frequently Asked Questions
What is the MOQ?
Stock RAL colors are typically 25-100 kg per color. Custom colors often start at 100 kg or more per color. Samples can usually be prepared at 1-5 kg, and we confirm the exact MOQ by finish, package and destination.
What is the lead time?
Stock colors are typically produced within 7 working days after approval; custom colors usually need 7-15 working days. QC and packing add 1-3 working days. Sea freight from Xiamen/Fuzhou is often 25-45 days, while air freight is often 3-10 days.
Can you match RAL, Pantone or a physical sample?
Yes. Send RAL/Pantone, a physical panel or both. We prepare a test panel and technical data sheet for approval. Stock RAL is faster; custom matching is normally included in the 7-15 working day development window.
What should I send for a technical recommendation?
Send substrate, application environment, cure oven range, required film thickness, gloss/texture, certification target and annual volume. Our engineers will confirm the resin system and final technical data sheet before production.
Which certifications can you support?
SGS testing, RoHS and REACH documentation are commonly available. WRAS, ACS and other market-specific approvals depend on the selected system; request them with your specification so we confirm the exact product and batch documents.
Export Buyer Note
For PVDF programs, confirm architectural warranty testing, color/gloss retention targets, extrusion alloy and project location. Typical supply is 25-100 kg for stock RAL colors, 100 kg or more for custom colors, and 1-5 kg qualification samples. Ask for the selected system’s COA, SDS and applicable market declarations before production.
